DR 6010C
DR 6010C
Simple addition to boost efficiency
Welcome the newly developed 3-line image sensor technology in the DR 6010C, which allows scans at an eye-raising 60ppm. All this can be achieved by any user, with one-touch job buttons.
- Scan size: up to A4
- Speed: up to 60ppm / 120ipm
- Connect with USB 2.0
Description
Fast and efficient handling
Featuring a versatile dual paper path, the DR 6010C handles diverse document types comfortably and effortlessly. The default U-turn path processes all your basic documents rapidly and smoothly, while the Straight Path feeder can process thicker items such as ID cards. For non-standard paper types such as multi-sheet carbonless paper, switch from automatic to manual sheet feeding mode to keep your scanning in smooth operation.
Energy-efficient
The DR 6010C requires less energy to operate, thereby also reducing running costs. Along with an auto power on / off, which smartly reduces energy consumption when not in use, the DR 6010C does its part to protect the environment, without compromising features or performance.
Auto-shading mechanism
Document quality control is maintained and kept consistent by the DR 6010Cās automatic calibration process. Prior to each scan job, the image sensor shifts to calibrate itself against a special white shading surface to ensure uniform image quality with impressive precision and clarity each and every time.
Bundled Software
Specifications
General
| Bundled Software | CapturePerfect, Job Registration Tool, VRS |
| Dimensions (W x D x H) |
Trays closed: 318 Ć 278 Ć 185.5 mm Trays open: 318 x 545 x 187 mm |
| Ejection pockets | – |
| Interface | Hi-speed USB 2.0 |
| MICR | – |
| On-Board Jogger | – |
| Operating Environment |
Temperature: 10 – 32.5Ā°C Humidity: 20 – 80% RH |
| Supported Operating System | Windows |
| Options / Consumables | Barcode Module, Exchange Roller Kit, Flatbed Scanner Unit 102 |
| Power | AC 220 ā 240 V |
| Power Consumption |
Scanning: 33 W, Sleep Mode: 2.7W |
| Weight | Approx. 6.5 kg |
Scanning Document
| Feeding Method | Automatic or manual |
| Document thickness – Plain Paper |
U-turn or straight path, feeding with separate mode Weight: 52 ā 128 g/m2 Thickness: 0.06 ā 0.15 mm U-turn path, feeding with bypass mode Straight path, non-separate feeding |
| Document thickness – Postcard | – |
| Document thickness – Business Card | – |
| Document thickness – Card (ISO/IEC compliant) | 0.76 mm or less |
| Document thickness – Passport | – |
| Feeding Capacity | 100 sheets |
| Document size – Plain Paper (A4/LTR) |
Width: 53 ā 219 mm, Length: 70 ā 356 mm Document size up to 297 Ć 420 mm in Folio mode, document length up to 3,000 mm in Long Document Mode. |
| Document size – Long Document Mode | Up to 3,000 mm |
| Document size – Postcard |
Width: 89 ā 108 mm, Length: 127 ā 152 mm |
| Document size – Business card |
Width: 53 ā 55 mm, Length: 70 ā 91 mm (Vertical feeding only) |
| Document size – Card (ISO/IEC compliant) | 54 x 86 mm (Straight path, non-separate feeding only) |
| Document size – Passport | – |
| Document size – Plastic card | – |
| Document size – Magnetic card | – |
Scan
| Light source | LED (red, green, and blue) |
| Maximum Resolution | 600 dpi |
| Scan Resolution | 100 x 100dpi, 150 x 150dpi, 200 x 200dpi, 240 x 240dpi, 300 x 300dpi, 400 x 400dpi, 600 x 600dpi |
| Scanner Element | 3-line CIS |
| Scanner Type | Desktop sheetfed scanner |
| Scanning Modes | Black and white, Error diffusion, Advanced Text Enhancement, Advanced Text Enhancement II, 256-level gray, 24-bit color |
| Scanning Side | Simplex / Duplex |
| Scanning speed |
A4 / LTR, Portrait, 200dpi: Black and White: 60ppm (simplex) / 120ipm (duplex) Grayscale: 60ppm (simplex) / 120ipm (duplex) Colour: 60ppm (simplex) / 120ipm (duplex) |
| Suggested Daily Volume (Scans) | 7500 |
Specifications are subject to change without notice.
- Scanning speed may vary depending on PC environment, scanner settings, and other factors
