DR 6010C

DR 6010C

Simple addition to boost efficiency

Welcome the newly developed 3-line image sensor technology in the DR 6010C, which allows scans at an eye-raising 60ppm. All this can be achieved by any user, with one-touch job buttons.

  • Scan size: up to A4
  • Speed: up to 60ppm / 120ipm
  • Connect with USB 2.0
Categories: ,
Description

Description


Fast and efficient handling

Featuring a versatile dual paper path, the DR 6010C handles diverse document types comfortably and effortlessly. The default U-turn path processes all your basic documents rapidly and smoothly, while the Straight Path feeder can process thicker items such as ID cards. For non-standard paper types such as multi-sheet carbonless paper, switch from automatic to manual sheet feeding mode to keep your scanning in smooth operation.


Energy-efficient

The DR 6010C requires less energy to operate, thereby also reducing running costs. Along with an auto power on / off, which smartly reduces energy consumption when not in use, the DR 6010C does its part to protect the environment, without compromising features or performance.


Auto-shading mechanism

Document quality control is maintained and kept consistent by the DR 6010C’s automatic calibration process. Prior to each scan job, the image sensor shifts to calibrate itself against a special white shading surface to ensure uniform image quality with impressive precision and clarity each and every time.


Bundled Software

  • CapturePerfect
  • KOFAX VRS Basic
  • Specifications

    Specifications

    General

    Bundled Software CapturePerfect, Job Registration Tool, VRS
    Dimensions (W x D x H) Trays closed: 318 × 278 × 185.5 mm
    Trays open: 318 x 545 x 187 mm
    Ejection pockets
    Interface Hi-speed USB 2.0
    MICR
    On-Board Jogger
    Operating Environment Temperature: 10 – 32.5°C
    Humidity: 20 – 80% RH
    Supported Operating System Windows
    Options / Consumables Barcode Module, Exchange Roller Kit, Flatbed Scanner Unit 102
    Power AC 220 – 240 V
    Power Consumption Scanning: 33 W,
    Sleep Mode: 2.7W
    Weight Approx. 6.5 kg

    Scanning Document

    Feeding Method Automatic or manual
    Document thickness – Plain Paper U-turn or straight path, feeding with separate mode
    Weight: 52 – 128 g/m2
    Thickness: 0.06 – 0.15 mm

    U-turn path, feeding with bypass mode
    Weight: 42 – 157 g/m2
    Thickness: 0.05 – 0.2 mm

    Straight path, non-separate feeding
    Weight: 42 – 546 g/m2
    Thickness: 0.05 – 0.66 mm

    Document thickness – Postcard
    Document thickness – Business Card
    Document thickness – Card (ISO/IEC compliant) 0.76 mm or less
    Document thickness – Passport
    Feeding Capacity 100 sheets
    Document size – Plain Paper (A4/LTR) Width: 53 – 219 mm,
    Length: 70 – 356 mm
    Document size up to 297 × 420 mm in Folio mode, document length up to 3,000 mm in Long Document Mode.
    Document size – Long Document Mode Up to 3,000 mm
    Document size – Postcard Width: 89 – 108 mm,
    Length: 127 – 152 mm
    Document size – Business card Width: 53 – 55 mm,
    Length: 70 – 91 mm
    (Vertical feeding only)
    Document size – Card (ISO/IEC compliant) 54 x 86 mm (Straight path, non-separate feeding only)
    Document size – Passport
    Document size – Plastic card
    Document size – Magnetic card

    Scan

    Light source LED (red, green, and blue)
    Maximum Resolution 600 dpi
    Scan Resolution 100 x 100dpi, 150 x 150dpi, 200 x 200dpi, 240 x 240dpi, 300 x 300dpi, 400 x 400dpi, 600 x 600dpi
    Scanner Element 3-line CIS
    Scanner Type Desktop sheetfed scanner
    Scanning Modes Black and white, Error diffusion, Advanced Text Enhancement, Advanced Text Enhancement II, 256-level gray, 24-bit color
    Scanning Side Simplex / Duplex
    Scanning speed A4 / LTR, Portrait, 200dpi:
    Black and White: 60ppm (simplex) / 120ipm (duplex)
    Grayscale: 60ppm (simplex) / 120ipm (duplex)
    Colour: 60ppm (simplex) / 120ipm (duplex)
    Suggested Daily Volume (Scans) 7500

    Specifications are subject to change without notice.

    • Scanning speed may vary depending on PC environment, scanner settings, and other factors
