imageRUNNER 1643i/1643iF

High in productivity, small in size

Introducing a compact A4 mono multifunction device with fast scanning capabilities and advanced mobile connectivity. Reliable and versatile, the iR1643 series offers a wide range of functions tailored to suit the demands of busy work groups.

A4 Monochrome
Print speed of up to 43 pages per minute

Categories: Digital Copiers, Printers

Description
Specifications

Description

Features

Application Library

The Application Library is packed with innovations to help you work smarter and more efficiently than ever. You can print frequently-used forms from the printer, or personalise the printer with your corporate logo with just a tap of the button.

Increased Productivity

Improve your workflow efficiency with fast outputs, large paper input capacity and rich media support. Single-pass document feeder with automatic, two-sided scanning ensures document digitisation processing is at its optimum..

Intuitive Control

The iR1643 series features a simple to operate and intuitive colour touchscreen, allowing for easy customisation of day-to-day tasks via selectable onscreen icons.

High Security

Control access and keep your files confidential with a range of advanced security and encryption options. The iR1643 Series also include latest technology to verify that the device boot process, firmware, and applications initialise without alterations or tampering.

Mobile Connectivity

Print, scan, or send documents from any portable device via various mobile connections. With Canon’s latest mobile business solution, you can print documents, photos and web pages with just one app. Click here to find out more!

Specifications

Main Unit

Machine Type	Monochrome A4 Laser Multifunctional
Core Functions	iR1643iF: Print, Copy, Scan, Send and Fax iR1643i: Print, Copy, Scan and Send
Control Panel	5 inch TFT LCD WVGA Colour Touch panel
Memory	Standard: 1.0GB RAM
Interface Connection
iR1643iF	NETWORK Standard: 1000Base-T/100Base-TX/10-Base-T, Wireless LAN (IEEE 802.11 b/g/n), NFC, Wi-Fi Direct Connection OTHERS Standard: USB 2.0 (Host) x2, USB 2.0 (Device) x1
iR1643i	NETWORK Standard: 1000Base-T/100Base-TX/10-Base-T, Wireless LAN (IEEE 802.11 b/g/n), Wi-Fi Direct Connection OTHERS Standard: USB 2.0 (Host) x2, USB 2.0 (Device) x1
Memory Media	Standard: USB Memory
Network Security	Standard: IP/Mac Address Filtering, IPSEC, TLS Encrypted Communication, SNMP V3.0, IEEE 802.1X, IPv6, SMTP Authentication, POP Authentication before SMTP
Document Security	Standard: Secure Print, Encrypted PDF, Device signature
Paper Supply Capacity (A4, 80gsm)	Standard: 650 sheets Paper Cassette: 550-sheet Multi-purpose tray: 100-sheet Maximum: 2,300 sheets (with PAPER FEEDER PF-C1x3)
Paper Output Capacity (A4, 80 gsm)	150 sheets
Supported Media Types	Upper Cassette 1: Thin, Plain, Thick, Colour, Recycled, Bond Multi-purpose tray: Thin, Plain, Thick, Colour, Recycled, Bond, Label, Envelope
Supported Media Sizes	Upper Cassette 1: Standard size: A4, B5, A5, A5R, A6 Custom size: Min. 105.0 x 148.0 mm up to 216.0 x 355.6 mm Multi-purpose tray: Standard size: A4, B5, A5, A5R, A6, Index Card, Envelopes [No. 10(COM 10), Monarch, ISO-C5, DL] Custom Size: Min. 76.2 x 127.0 mm up to 216.0 x 355.6 mm
Supported Media Weights	Upper Cassette 1: 60 to 120 gsm Multi-purpose tray: 60 to 199 gsm Duplex: 60 to 120 gsm
Warm-up Time (Time from device power-on until copy ready, not print reservation)	From Power On: 14 Seconds or Less^*1 From Sleep Mode: 4 Seconds or Less
Dimensions (W x D x H)	iR1643iF: 494 x 595 x 452 mm (with the Multi-purpose tray extended) iR1643i: 480 x 595 x 452 mm (with the multi purpose tray extended)
Installation Space (W x D)	iR1643iF: 708 x 1,105 mm (with Cassette open + 100 mm gap around the main body) iR1643i: 694 x 1,105 mm (with Cassette open + 100 mm gap around the main body)
Weight	Standard: Approx. 19 kg without toner

Print

Print Speed (BW)	43 ppm (A4)
Print Resolution (dpi)	600 × 600
Page Description Languages	iR1643iF: UFR II, PCL6, PCL5, Adobe®PostScript®3™ iR1643i: UFR II, PCL6, PCL5, Optional: Adobe®PostScript®3™
Direct Print	Direct printing available from USB memory, LPR Supported file types: TIFF, JPEG, PDF and XPS (only LPR)
Fonts	PCL fonts: 93 Roman PS fonts: 136 Roman
Operating System	UFRII/PCL/PS: Windows®7/8.1/10/Server2008/Server2008 R2/Server2012/Server2012 R2/Server2016, Mac OS X (10.9 or later)

Copy

Copy Speed (ppm)	43 ppm (A4)
First-Copy-Out Time (A4)	Platen: Approx. 6.3 seconds or less ADF: Approx. 6.4 seconds or less
Copy resolution (dpi)	Reading / Printing: 600 x 600 Printing: 600 x 600
Multiple Copies	Up to 999 copies
Copy Density	Automatic or Manual (9 Levels)
Magnification	25% – 400% (1% Increments)
Preset Reductions	25%, 50%, 70%, 81%, 86%
Preset Enlargements	115%, 122%, 141%, 200%, 400%

Scan

Document Feeder Type	1PDS
Paper Capacity	A4: 50 sheets (80 gsm)
Acceptable Originals and Weights	Platen: Sheet, Book, 3-Dimensional Objects (Height: up to 20mm) Document Feeder sheet media weight : 1-sided/2-sided continuous scanning: 50 to 105 gsm
Supported Media Sizes	Sheet media size: A4R, B5R, A5R, A6R Custom size: 105×128 mm to 215.9×355.6 mm
Scan Speed (ipm: BW/CL; A4)	Copy: 1-sided Scanning: 20 2-sided Scanning: 34 Send: 1-sided Scanning(BW/CL): 38/13 2-sided Scanning(BW/CL): 70/26
Scan Resolution (dpi)	Copy: 600 x 600 Send (Push, Pull)/Fax: up to 600 x 600
Pull Scan Specifications	ScanGear MF For both TWAIN and WIA ScanGear MF For both TWAIN and WIA Windows® 7/8.1 / 10 / Server2008 / Server2008 R2 / Server2012 / Server2012 R2 / Server2016, Mac OS X (10.9 or later)
Scan Method	Send functionality available on both models Scan to USB Memory Key TWAIN/WIA Pull scanning available on both models

Send

Destination	E-mail/Internet FAX (SMTP), SMB, FTP
Address Book	LDAP (50)/Local (300)/Speed dial (281)
Send Resolution (dpi)	Push: 196 x 204 (I-FAX) 300 x 300 (email/SMB/FTP) Pull: Max. 9,600 x 9,600
Communication Protocol	File: FTP, SMB E-mail/I-Fax: SMTP, POP3, I-Fax (Simple)
File Format	TIFF, JPEG, PDF(Compact, Searchable, Encrypted, Digital Signature)

Fax

Optional / Standard	iR1643iF: Standard iR1643i: Not Applicable
Maximum Number of Connection Lines	iR1643iF: 1 iR1643i: Not Applicable
Modem Speed	iR1643iF: Super G3: 33.6 kbps G3: 14.4 kbps iR1643i: Not Applicable
Compression Method	iR1643iF: MH, MR, MMR, JBIG iR1643i: Not Applicable
Resolution (dpi)	iR1643iF: 400 x 400 (Ultrafine), 200 x 400 (Superfine), 200 x 200 (Fine/ Photo), 200 x 100 (Normal) iR1643i: Not Applicable
Sending / Recording Size	iR1643iF: A4, B5^2, A5^2, A6^*2 iR1643i: Not Applicable
FAX / Memory	iR1643iF: Up to 512 pages iR1643i: Not Applicable
Speed Dials	iR1643iF: Max. 281 coded-dials, max. 299 group dials iR1643i: Not Applicable
Group Dials / Destinations	iR1643iF: Max. 299 dials iR1643i: Not Applicable
Sequential Broadcast	iR1643iF: Max. 310 addresses iR1643i: Not Applicable
Memory Backup	iR1643iF: Yes iR1643i: Not Applicable

Store

Memory Media

Standard: USB Memory

Security

Network	Standard: IP/Mac Address Filtering, IPSEC, TLS Encrypted Communication, SNMP V3.0, IEEE 802.1X, IPv6, SMTP Authentication, POP Authentication before SMTP
Document	Standard: Secure Print, Encrypted PDF, Device signature

Environmental

Operating Environment	Temperature: 10 to 30 ºC (50 to 86 ºF) Humidity: 20 to 80 % RH (Relative Humidity)
Power Source	AC220-240V:3.9A,50/60Hz
Power Consumption	Maximum: Approx. 1420W or less

Consumables

Toner Cartridge/s	Toner T06 Black
Toner (Estimated Yield @ 6% Coverage)	Toner T06 Black: 20,500 impressions (A4)

Paper Supply Options

Feeder Options

PAPER FEEDER PF-C1

Paper Capacity:550 sheets (80 gsm)

Paper Size: A4,B5,A5,A5R,A6,
Custom size:105.0 x 148.0mm to 216.0 x 355.6mm

Dimensions (W x D x H): 480 x 464 x 842^*3mm
Weight: Approx. 4.0 kg

Hardware Accessories

Card Readers

COPY CARD READER-F1

System and Controller options

Print Accessories	COPY CARD READER-F1, PS PRT KIT-CB1 AS, PS PRT KIT-CB1E, BARCODE PS PRT KIT-CB1E
Barcode Printing	BARCODE PRT KIT-E1E EU, BARCODE PRT KIT-E1
System Accessories	CONTROL I/F KIT-C1

Time from device power-on, until copy ready (not print reservation).
Sent as A4.
Attached to the main unit.
