imageRUNNER 2900i

Machine Type

A3 Monochrome Laser Multifunctional

Core Functions

Print, Copy, Scan, Send and Optional Fax

Control Panel

7 inch TFT LCD WVGA Colour Touch panel

Memory

Standard: 2.0 GB RAM

Storage

Standard: 64 GB eMMC (available space 30 GB)

Optional: 256 GB SSD

Interface Connection

NETWORK
Standard: 1000Base-T/100Base-TX/10Base-T, Wireless LAN (IEEE 802.11 b/g/n)

OTHERS
Standard: USB 2.0 (Host) x2, USB 2.0 (Device) x1

Paper Supply Capacity (A4, 80 gsm)

Standard: 1,200 sheets

(100 sheets Multi Purpose Tray

2 x 550 sheets paper cassette)

Maximum: 2,300 sheets (with Cassette Feeding Unit-AW1)

Paper Output Capacity (A4, 80 gsm)

Standard: 250 sheets

Maximum: 645 sheets (with Inner Finisher-L1 and Copy Tray-T2)

Supported Media Types

Multi-purpose Tray:

Thin, Plain, Heavy, Recycled, Coated^*1, Colour, Tracing, Bond, Transparency, Labels, Pre-punched, Letterhead, Envelope, Postcard

Upper Cassette:

Thin, Plain, Heavy, Recycled, Colour, Bond, Transparency, Pre-punched, Letterhead, Envelope^*2, Postcard

Lower Cassette:

Thin, Plain, Heavy, Recycled, Colour, Bond, Transparency, Pre-punched, Letterhead, Envelope^*3, Postcard

Supported Media Sizes

Multi-purpose Tray:

Standard size: SRA3, A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R

Custom size: 98.4 x 139.7 mm to 320.0 x 457.2 mm

Free size: 100.0 x 148.0 mm to 304.8 x 457.2 mm

Envelopes: COM10 No.10, Monarch, ISO-C5, DL

Envelope custom size: 98.0 x 98.0 mm to 320.0 x 457.2 mm

Upper Cassette:

Standard size: A4, A5, A5R, A6R, B5

Custom size: 105.0 x 148.0 mm to 297.0 x 215.9 mm

Envelopes: ISO-C5

Lower Cassette:

Standard size: A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R

Custom size: 105.0 x 148.0 mm to 304.8 x 457.2 mm

Envelopes^*4: COM10 No.10, Monarch, DL

Supported Media Weights

Multi-purpose Tray:

52 to 300 gsm^{*1 *5}

Upper/Lower Cassette:

52 to 256 gsm

Duplex:

52 to 220 gsm

Warm-up Time (Quick start mode: ON)

4 Seconds or Less^*6

From Sleep Mode: 10 seconds or less

From Power On: 10 seconds or less^*7

Dimensions (W x D x H)

With DADF-BA1 (iR2945i/iR2935i): 565 x 687 x 891 mm

With DADF-AZ2 (iR2930i/iR2925i): 565 x 693 x 852 mm

Installation Space (W x D)

iR2945i/iR2935i:
1,286 x 1,116 mm (with DADF-BA1 + Inner Finisher tray max extended + Copy Tray-T2 max extended + paper cassette opened）

iR2930i/iR2925i:
1,286 x 1,122 mm (with DADF-AZ2 + Inner Finisher tray max extended + Copy Tray-T2 max extended + paper cassette opened)

Weight Including Toner

With DADF-BA1 (iR2945i/iR2935i): Approx. 67 kg

With DADF-AZ2 (iR2930i/iR2925i): Approx. 66 kg

Print Speed (BW)

iR2945i:

1-sided: Up to 45 ppm (A4), Up to 22 ppm (A3), Up to 32 ppm (A4R)

2-sided: Up to 45 ppm (A4), Up to 22 ppm (A3), Up to 32 ppm (A4R)

iR2935i:

1-sided: Up to 35 ppm (A4), Up to 17 ppm (A3), Up to 23 ppm (A4R)

2-sided: Up to 35 ppm (A4), Up to 17 ppm (A3), Up to 23 ppm (A4R)

iR2930i:

1-sided: Up to 30 ppm (A4), Up to 15 ppm (A3), Up to 20 ppm (A4R)

2-sided: Up to 30 ppm (A4), Up to 15 ppm (A3), Up to 20 ppm (A4R)

iR2925i:

1-sided: Up to 25 ppm (A4), Up to 15 ppm (A3), Up to 20 ppm (A4R)

2-sided: Up to 25 ppm (A4), Up to 15 ppm (A3), Up to 20 ppm (A4R)

Print Resolution (dpi)

600 × 600,
1,200 × 1,200 (half-speed)

Page Description Languages

Standard: UFRII

Option: PCL6, Adobe® PostScript®3™

Direct Print (RUI)

PDF, EPS, TIFF/JPEG, XPS

Printing from Mobile and Cloud Application

AirPrint, Mopria, Canon PRINT Business, uniFLOW Online and Universal Print

OS Standard Printing

Android, Windows® 10/11, Chrome OS, macOS (11.2.2 or later), iOS (15.2 or later), iPadOS

Fonts

PS fonts: 136 Roman

PCL fonts: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Andalé Mono WT J/K/S/T^*8 (Japanese, Korean, Simplified and Traditional Chinese), Barcode fonts^*9

Operating System

UFR II: Windows® 10/11/Server2012/Server2012 R2/Server2016/Server2019/Server2022, macOS(10.13 or later)

PCL: Windows® 10/11/Server2012/Server2012 R2/Server2016/Server2019/Server2022

PS: Windows® 10/11/Server2012/Server2012 R2/Server2016/Server2019/Server2022, macOS(10.13 or later)

PPD: Windows® 10/11, macOS(10.13 or later)

Copy Speed

iR2945i

1-sided: Up to 45 ppm (A4), Up to 22 ppm (A3), Up to 32 ppm (A4R)

2-sided: Up to 45 ppm (A4), Up to 22 ppm (A3), Up to 32 ppm (A4R)

iR2935i

1-sided: Up to 35 ppm (A4), Up to 17 ppm (A3), Up to 23 ppm (A4R)

2-sided: Up to 35 ppm (A4), Up to 17 ppm (A3), Up to 23 ppm (A4R)

iR2930i

1-sided: Up to 30 ppm (A4), Up to 15 ppm (A3), Up to 20 ppm (A4R)

2-sided: Up to 30 ppm (A4), Up to 15 ppm (A3), Up to 20 ppm (A4R)

iR2925i

1-sided: Up to 25 ppm (A4), Up to 15 ppm (A3), Up to 20 ppm (A4R)

2-sided: Up to 25 ppm (A4), Up to 15 ppm (A3), Up to 20 ppm (A4R)

First-Copy-Out Time (A4)

iR2945i: 5.3 seconds

iR2935i: 6.4 seconds

iR2930i: 7.0 seconds

iR2925i: 7.0 seconds

Copy Resolution (dpi)

600 x 600

Multiple Copies

Up to 9,999 copies

Copy Density

Automatic or Manual (9 Levels)

Magnification

Variable zoom: 25% to 400% (1% Increments)

Preset reduction/enlargement: 25%, 50%, 61%, 70%, 81%, 86%, 100% (1:1), 115%, 122%, 141%, 200%, 400%

Document Feeder Paper Capacity (80 gsm)

DADF-BA1: up to 100 sheets

DADF-AZ2: up to 50 sheets

Acceptable Originals and Weights

Platen: Sheet, Book and 3-Dimensional objects

Document Feeder media weight:

DADF-BA1 (for iR2945i/iR2935i):

1-sided scanning: 38 to 128 gsm (BW), 64 to 128 gsm (CL)

2-sided scanning: 50 to 128 gsm (BW), 64 to 128 gsm (CL)

DADF-AZ2 (for iR2930i/iR2925i):

1-sided scanning: 38 to 128 gsm

2-sided scanning: 52 to 128 gsm

Supported Media Sizes

Platen:
Max. scanning size: 297.0 x 431.8 mm

DADF-BA1 (for iR2945i/iR2935i):

A3, A4, A4R, A5, A5R, B4, B5, B5R, B6

Custom size: 139.7 x 128.0 mm to 297.0 x 431.8 mm

DADF-AZ2 (for iR2930i/iR2925i):

A3, A4, A4R, A5, A5R, B4, B5, B5R

Custom size: 148.0 x 128.0 mm to 297.0 x 431.8 mm

Scan Speed (ipm: BW/CL, A4)

DADF-BA1 (for iR 2945i/iR2935i):

1-sided Scanning: 70/70 (300 x 300 dpi, send), 51/- (600 x 600 dpi, copy)

2-sided Scanning: 35/35 (300 x 300 dpi, send), 25.5/- (600 x 600 dpi, copy)

DADF-AZ2 (for iR 2930i/iR2925i):

1-sided Scanning: 35/25 (300 x 300 dpi, send), 25/- (600 x 600 dpi, copy)

2-sided Scanning: 12/8 (300 x 300 dpi, send), 8/- (600 x 600 dpi, copy)

Scan Resolution (dpi)

Scan for Copy: 600 x 600

Scan for Send:
(Push) 600 x 600 (SMB/FTP/WebDAV/IFAX)
(Pull) 600 x 600

Scan for Fax: 600 x 600

Pull Scan Specifications

Colour Network ScanGear2. For both TWAIN and WIA

Supported OS: Windows® 10/11/Server2012/Server2012 R2/Server 2016/Server 2019/Server 2022

Destination

Standard: E-mail/Internet FAX (SMTP), SMB, FTP, WebDAV

Optional: Super G3 FAX

Address Book

LDAP (2,000) / Local (1,600) / One-touch (200)

Send Resolution (dpi)

Push: (CL) up to 300 x 300 / (BW) up to 600 x 600

Pull: (CL) up to 300 x 300 / (BW) up to 600 x 600

Communication Protocol

FTP: (TCP/IP), SMB3.1.1 (TCP/IP), WebDAV

Email/iFax: SMTP (send), POP3 (receive)

File Format

Standard: TIFF (MMR), JPEG^*10, PDF (Compact, OCR (Text Searchable), Optimize PDF for Web, Format to PDF/A-1b, Encrypt), XPS (Compact, OCR (Text Searchable)), PDF/XPS (Device Signature), Office Open XML (PowerPoint, Word)

Option: PDF (Trace & Smooth), PDF / XPS (User Signature)

Maximum Number of Connection Lines

1

Modem Speed

Super G3: 33.6 kbps

G3: 14.4 kbps

Compression Method

MH, MR, MMR, JBIG

Resolution (dpi)

200 x 100 dpi (Standard), 200 x 200 dpi (Fine), 200 x 400 dpi (Super Fine), 400 x 400 dpi (Ultra Fine)

Sending/Recording Size

Sending: A3, A4, A4R, A5^*11, A5R^*11, B4, B5^*12, B5R^*11

Receiving: A3, A4, A4R, A5, A5R, B4, B5, B5R

Fax Memory

Up to 30,000 pages (2,000 jobs)

Speed Dials

Max. 200

Group Dials/Destinations

Max. 199 dials

Sequential Broadcast

Max. 256 addresses

Memory Backup

Yes

Authentication and Access Control

User Authentication (Picture Login, Picture and PIN Login, Card Login, Username and Password Login, Function Level Login, Mobile Login), Department ID Authentication (Department ID and PIN Login, Function Level Login), uniFLOW^*13 (PIN Login, Picture Login, Picture and PIN Login, Card Login, Card and PIN Login, Username and Password Login, Department ID and PIN Login, Function Level Login), Access Management System (Access Control)

Document Security

Print Security (Secure Print, Encrypted SecurePrint, Forced Hold Printing, uniFLOW Secure Print^*14), Receive Data Security (Confidential Fax Inbox Forwarding Received Documents Automatically), Scan Security (Encrypted PDF, Device Signature PDF/XPS, User Signature PDF/XPS^*15), Send Data Security (Setting for requesting password input per transmission, Restricted E-mail/File send functions, Confirming FAX number, Allow/Restrict Fax Driver Transmissions, Allow/Restrict Sending from History, S/MIME Support)

Network Security

TLS 1.3, IPSec, IEEE802.1X authentication, SNMPv3, Firewall Functionality (IP/MAC Address Filtering), WPA3 support (Wi-Fi), Dual Network Support (Wired LAN/Wireless LAN, Wired LAN/Wired LAN), Enabling/Disabling (Network Applications, Remote UI, USB Interface), G3 FAX separation from LAN, USB Port separation from LAN, Scan and Send -Virus Concerns for E-mail Reception

Device Security

Standard Storage Initialize, Job Log Conceal Function, Checking MFD Software Integrity (Verify System at Startup, Automatic Recovery, Runtime Intrusion Detection)

Device Management and Auditing

Administrator Password, Digital Certificate and Key Management, Audit Log, Cooperating with External Security Audit System (Security Information and Event Management), Security Policy Setting

Operating Environment

Temperature: 10 to 30°C

Humidity: 20 to 80% RH (Relative Humidity)

Power Source

220-240V 50/60Hz 4A

Power Consumption

Maximum: Approx. 1,500 W

Sleep Mode: Approx. Wired LAN: 0.8 W^*16

Toner (Estimated Yield @ 6% Coverage)

NPG-90 Toner BK: 33,000 pages

Tracking and Reporting

uniFLOW Online Express / uniFLOW Online

Remote Management Tools

iW Management Console

Monitoring Service

Content Delivery System

Scanning Software

Colour Network ScanGear 2

Optimisation Tools

Canon Driver Configuration Tool

Document Publishing

iW Desktop

Cassette Feeding Unit-AW1

Paper Capacity: 550 sheets x 2 (1,100 sheets) (80 gsm)

Paper Type: Thin, Plain, Recycled, Colour, Heavy, Bond, Transparency, Pre-punched, Letterhead, Postcard

Paper Size: A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R

Custom Size: 105.0 x 148.0 mm to 304.8 x 457.2 mm

Paper Weight: 52 to 256 gsm

Power Source: From the Main Unit

Dimensions (W x D x H): 565 x 635 x 248 mm

Weight: Approx. 16.0 kg

Inner 2way Tray-M1

Tray Capacity (with 80 gsm paper)

Upper tray:
A4, A5, A5R, A6R, B5, B5R: up to 100 sheets

SRA3, A3, A4R, B4: up to 50 sheets

Lower tray (standard tray):
A4, A5, A5R, A6R, B5, B5R: up to 250 sheets

SRA3, A3, A4R, B4: up to 100 sheets

Paper Weight: 52 to 300 gsm

Dimensions (W x D x H): 428 x 405 x 88 mm

Weight: 0.7 kg

Copy Tray-T2

Capacity (with 80gsm paper):

A4, A5R, B5, B5R: 100 sheets

A3, A4R, B4: 75 sheets

Dimensions (W x D x H): 444 × 373 × 176 mm (attached to the main unit, when the extension tray is extended)

Weight: 0.5 kg

Inner Finisher-L1

Tray Capacity (with 80 gsm paper):

Upper Tray:
SRA3, A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R: Approx. 45 sheets

Lower Tray:
A4, A5, A5R, B5: Approx. 500 sheets

SRA3, A3, A4R, B4, B5R: 250 sheets
A6R: 30 sheets

Envelope: 10 sheets

Paper Weight: 52 to 300 gsm

Staple Position: Corner, Double

Staple Capacity:

A4, B5: 50 sheets (52 to 90 gsm)

A4R: 40 sheets (52 to 90 gsm)

A3, B4: 30 sheets (52 to 90 gsm)

Eco Staple:

A3, A4, B4, B5:
10 sheets (52 to 64 gsm)

8 sheets (65 to 81.4 gsm)

6 sheets (82 to 105 gsm)

Staple On Demand: Approx. 40 sheets (80 gsm)

Dimensions (W x D x H): 587 × 525 × 225 mm (attached to the main unit, when the extension tray is extended)

Weight: Approx. 9.1 kg

Inner 2/3 Hole Puncher-D1

(Requires Inner Finisher-L1)

Two or Three Holes

Acceptable Punch Paper Weight: 52 to 300 gsm

Acceptable Punch Paper Size:

Two holes A3, A4, A4R, A5, B4, B5, B5R

Three holes A3, A4, B4, B5

Inner 2/4 Hole Puncher-D1

(Requires Inner Finisher-L1)

Two or Four Holes

Acceptable Punch Paper Weight: 52 to 300 gsm

Acceptable Punch Paper Size:

Two holes A3, A4, A4R, A5, B4, B5, B5R

Four holes A3, A4

Card Readers

IC Card Reader Attachment-B4

Option Attachment kit for Reader-A2

Others

DADF-AZ2

DADF-BA1

Platen Cover-Y3

Platen Cover Type Z

Platen Cover-Y3

Utility Tray-B1

Media Adjustment Kit-A1

Print Accessories

PS Printer Kit-BT1

PCL Printer Kit-BT1

PCL International Font Set-A1

Barcode Printing Kit-D1

Send Accessories

Universal Send Trace & Smooth PDF Kit-A1

Universal Send Digital User Signature Kit-C1

Fax Accessories

Super G3 FAX Board-BN1
Remote Fax Kit-A1

Storage Accessories

Optional Data Storage Kit-A1

Interface Accessories

Copy Control Interface Kit-D1

ADF Access Handle-A1

Staple Cartridges

Staple-P1
