R40
R40
An easy-to-use scanner that enhance productivity and organization
With a compact design, R40 supports quick scanning and fast conversion of documents into searchable digital forms with bundled software.
- Feeder capacity: 60 sheets
- Speed: up to 40 ppm / 80 ipm
- Up to 600 dpi in scanning resolution
Description
Easy to Use
Easy installation and setup makes R40 the ideal scanner for desktop use.
The single button operation makes scanning fast and efficient for users as documents may be scanned quickly and easily.
Up to 9 shortcuts can be programmed, simplifying your scanning even further.
Quick and High Quality Scans
Equipped with fast scanning speed of 40 ppm, R40 delivers high-quality scans for both sides of your documents simultaneously.
In addition, the Automatic Document feeder can hold up to 60 sheets of paper.
Reliable Paper Feeding
Equipped with precise and accurate and feeding roller, R40 efficiently supports robust scanning of a variety of documents types including thick and thin papers, receipts, business cards, and others.
Specifications
General
| Bundled Software |
Windows & Mac: TWAIN Driver, Canon CaptureOnTouch Windows only: Readiris PDF Software, Cardiris business card software |
| Dimensions (W x D x H) | 291 x 250 x 245 mm (trays closed) |
| Interface | USB 2.0 |
| Supported Operating System | Windows 7 SP1 or later (32bit/64bit), Windows 8.1 (32bit/64bit), Windows 10 (32/64-bit), MacOS 10.12, MacOS 10.13, MacOS 10.14, MacOS 10.15 |
| Options / Consumables | Exchange Roller Kit |
| Power | 220-240 V |
| Power Consumption | 22 W or less (Sleep Mode: 1.7 W) |
| Weight | Approx. 2.8 kg |
Scanning Document
| Feeding Method | Automatic or Manual |
| Document thickness – Plain Paper |
Weight: 27 to 209 g/m² Thickness: 0.04 mm to 0.25 mm |
| Document thickness – Postcard | 128 – 300 g/m² (0.15 – 0.4 mm) |
| Document thickness – Business Card | Less than 0.45 mm |
| Document thickness – Card (ISO/IEC compliant) | Less than 1.4 mm |
| Feeding Capacity | 60 sheets |
| Document size – Plain Paper (A4/LTR) |
Width: 50.8 – 216 mm Length: 54 – 356 mm |
| Document size – Long Document Mode |
Up to 3,000 mm *Less than 2,700 mm in 400 / 600 dpi |
| Document size – Postcard |
Width: 88.9 – 108 mm Length: 127 – 152.4 mm |
| Document size – Business card |
Width: 50 mm Length: 85 mm or larger |
| Document size – Card (ISO/IEC compliant) |
54 mm x 86 mm (Embossed card can be scanned) |
| Document size – Plastic card | 54 mm x 86 mm |
Scan
| Light source | LED (Red, Green, and Blue) |
| Maximum Resolution | 600 dpi |
| Scan Resolution | 100 x 100 dpi, 150 x 150 dpi, 200 x 200 dpi, 240 x 240 dpi, 300 x 300 dpi, 400 x 400 dpi, 600 x 600 dpi |
| Scanner Element | One-line contact image sensor (CIS) |
| Scanner Type | Desktop sheet-fed scanner |
| Scanning Modes | Black and white, Error diffusion, Advanced Text Enhancement, Advanced Text Enhancement II, 256-level gray, 24-bit color |
| Scanning Side | Simplex / Duplex |
| Scanning speed |
A4, 200 dpi: Black and White: 40 ppm (simplex) / 80 ipm (duplex) Grayscale: 40 ppm (simplex) / 80 ipm (duplex) Colour: 30 ppm (simplex) / 60 ipm (duplex) |
| Suggested Daily Volume (Scans) | 4,000 |
